MERGE SORT IN JAVA

MERGE SORT IN JAVA

package mergesort;

import java.util.Random;

import java.util.Scanner;

public class Demo {

public static void Display(int A[]){

for(int i=0;i<A.length;i++){

System.out.print(A[i]+" ");

}

}

public static void mergesort(int A[]){

int n=A.length;

if(n<2){

return;

}

int mid=n/2;

int LA[]=new int[mid];

int RA[]=new int[n-mid];

for(int i=0;i<mid;i++){

LA[i]=A[i];

}

for(int i=mid;i<n;i++){

RA[i-mid]=A[i];

}

mergesort(LA);

mergesort(RA);

merge(A,LA,RA);

}

public static void merge(int A[],int LA[], int RA[]){

int n=A.length;

int nl=LA.length;

int nr=RA.length;

int i=0,j=0,k=0;

while(i< nl && j<nr){

if(LA[i]<RA[j]){

A[k]=LA[i];

i++;

k++;

}else{

A[k]=RA[j];

j++;

k++;

}

}

while(i<nl){

A[k]=LA[i];

i++;

k++;

}

while(j<nr){

A[k]=RA[j];

j++;

k++;

}

}

public static void main(String args[]){

Scanner in=new Scanner(System.in);

Random random=new Random();

int s;

System.out.println("Enter the size of the Array");

s=in.nextInt();

int A[]=new int[s];

for(int i=0;i<s;i++){

A[i]=random.nextInt(100);

}

Display(A);

mergesort(A);

System.out.println("\nSorted");

Display(A);

}

}

QUICK SORT IN JAVA

QUICK SORT IN JAVA

package quicksort;

import java.util.Random;

import java.util.Scanner;

public class Demo {

public static void Display(int A[]){

for(int i=0;i<A.length;i++){

System.out.print(A[i]+" ");

}

}

public static void quicksort(int A[],int start, int end){

if(start>=end){

return;

}

int pIndex=partition(A,start,end);

quicksort(A,start,pIndex-1);

quicksort(A,pIndex+1,end);

}

public static int partition(int a[],int s, int e){

int piviot = a[e];

int pindex=s;

for(int i=s;i<e;i++){

if(a[i]<=piviot){

// swapping

int temp= a[pindex];

a[pindex]=a[i];

a[i]=temp;

pindex++;

}

}

a[e]=a[pindex];

a[pindex]=piviot;

return pindex;

}

public static void main(String args[]){

Scanner in=new Scanner(System.in);

Random random=new Random();

int s;

System.out.println("Enter the size of the Array");

s=in.nextInt();

int A[]=new int[s];

for(int i=0;i<s;i++){

A[i]=random.nextInt(100);

}

Display(A);

quicksort(A,0,s-1);

System.out.println("\nSorted");

Display(A);

}

}

Dijkstra's algorithm in java

Dijkstra's algorithm in java

package dijkstra;

import java.util.Scanner;

public class Demo {

int no_nodes;

int matrix[][];

int s; // source

int d[];// distance

int p[]; // parent

boolean visited[]; // to track visited node

Scanner in=new Scanner(System.in);

public void input(){

System.out.println("Enter no. of Nodes");

no_nodes=in.nextInt();

matrix=new int[no_nodes][no_nodes];

d=new int[no_nodes];

p=new int[no_nodes];

visited=new boolean[no_nodes];

System.out.println("Enter connection matrix");

System.out.print("  ");

for(int i=0;i<no_nodes;i++){

char ch=(char)(65+i);

System.out.print(ch+"\t");

}

System.out.println();

for(int i=0;i<no_nodes;i++){

System.out.print((char)(65+i));

for(int j=0;j<no_nodes;j++){

matrix[i][j]=in.nextInt();

}

System.out.println();

}

}

public void initialize(){

for(int i=0;i<no_nodes;i++){

d[i]=1000; // infinity

p[i]=-1 ;// nil for parents

visited[i]=false;

}

d[s]=0;

}

public int findVertex(){

int min=1000;

int vertex=0;

for(int i=0;i<no_nodes;i++){

if(visited[i]==false && d[i]<min){

min=d[i];

vertex=i;

}

visited[vertex]=true;

}

return vertex;

}

public void algorithm(){

System.out.println("Enter source");

s=in.nextInt();

initialize();

int c=no_nodes;

while(c>0){

// find vertex to go

int vertex=findVertex();

c--;

for(int i=0; i<no_nodes;i++){

if(matrix[vertex][i]>0){

// relax

int dis=matrix[vertex][i];

if(dis+d[vertex]<d[i]){

d[i]=dis+d[vertex];

p[i]=vertex;

}

}

}

}

System.out.println("Source= "+(char)(65+s));

System.out.println();

System.out.print(" ");

System.out.print("\tD"+"\tP\n");

for(int i=0;i<no_nodes;i++){

System.out.print((char)(65+i)+"\t");

System.out.print(d[i]+"\t");

System.out.print((char)(65+p[i])+"\n");

}

}

public static void main(String args[]){

Demo obj=new Demo();

obj.input();

obj.algorithm();

}

}

banker's algorithm in java

Banker's algorithm in java

optimal page replacement in java

Optimal page replacement in java

package pagereplacement;

import java.util.LinkedList;

import java.util.Queue;

import java.util.Scanner;

public class Demo {

String ref="";

int size=0;

int pf=0;

char frame[];

int fc=0;

Scanner input=new Scanner(System.in);

public void input(){

System.out.println("Enter Ref. String");

ref=input.next();

System.out.println("Enter Frame size");

size=input.nextInt();

frame=new char[size];

}

public boolean search(char ch){

for(int i=0;i<fc;i++){

char temp=frame[i];

if(temp==ch){

return true;

}

}

return false;

}

public int future(char ch, int pos){

int result=ref.length()+1;

for(int i=pos+1;i<ref.length();i++){

char temp=ref.charAt(i);

if(temp==ch){

if(i<result){

result=i;

}

}

}

return result;

}

public void optimal(){

System.out.println("Lenght="+ref.length());

for(int i=0;i <ref.length();i++){

char ch=ref.charAt(i);

if(search(ch)){

}else{

// page fault

System.out.print("Page fault At index "+i);

pf++;

if(fc<size){

frame[fc]=ch;

fc++;

}else{

int optimal[]=new int[size];

for(int j=0;j<size;j++){

optimal[j]=future(frame[j],i);

}

// to find the page to be replaced

int index=0;

int max=optimal[0];

for(int j=1;j<size;j++){

if(optimal[j]>max){

max=optimal[j];

index=j;

}

}

// replace page

System.out.print(" and page "+ frame[index]+" is repaced by "+ch);

frame[index]=ch;

}

System.out.println();

}

}

System.out.println("No. of Page fault="+pf);

}

public static void main(String args[]){

Demo obj=new Demo();

obj.input();

obj.optimal();

}

}

//70120304230321201701

Process Scheduling Simulator - SJF | FCFS | RoundRobin

Process Scheduling Simulator - SJF | FCFS | RoundRobin

// APP CLASS

import java.awt.*;
import java.awt.event.ActionEvent;
import java.awt.event.ActionListener;
import java.awt.event.KeyAdapter;
import java.awt.event.KeyEvent;
import java.awt.image.BufferedImage;
import java.io.File;
import java.sql.Time;
import java.util.LinkedList;
import java.util.Queue;

import javax.imageio.ImageIO;
import javax.swing.*;


public class App extends JFrame {

JFrame f1,f2,finput,f3;
ButtonGroup group;
JRadioButton r1,r2,r3;
Font font1;
JButton jb1,add,delete,start,back,insert,done,colorc,start2;
JLabel avgTime;
JTable table;
JScrollPane scrollPane,scrollPane2;
String dataValues[][];
String readyData[][];
JTextField txt1,txt2,txt3;//
int c,readyc;//counter
float AvgWaitTime=0;
float displayResult=0;
int totalTime=0;
String columnNames[] = { "S.No", "JOB_ID", "CPU BURST","ARRIVAL TIME" };
Color color;
JobPool jobpool; // object of JobPool Class  to store all process
Animation animation;
PaintReadyQueue prqObj;
GanttChart gcObj;
ProgessBar pbObj;
//
public Queue<Process> JobQueue,ReadyQueue;
//
public App(){
c=0;// counter
color=Color.WHITE; // Color variable for process by default white
jobpool=new JobPool();
animation=new Animation();
f1=new JFrame();
f1.setSize(600, 420);
f1.setVisible(true);
f1.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
f1.setResizable(false);
f1.setLocationRelativeTo(null);
f1.setLayout(null);
f1.setTitle("PROCESS SCHEDULING | DEVELOPED BY SHAHARYAR SHAUKAT");
//
f2=new JFrame();
f2.setSize(800, 600);
f2.setVisible(false);
f2.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
f2.setResizable(false);
f2.setLocationRelativeTo(null);
f2.setLayout(null);
f2.setTitle("PROCESS SCHEDULING | DEVELOPED BY SHAHARYAR SHAUKAT");
//
f3=new JFrame();
f3.setSize(1000, 670);
f3.setVisible(false);
f3.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
f3.setResizable(false);
f3.setLocationRelativeTo(null);
f3.setLayout(null);
f3.setTitle("PROCESS SCHEDULING | DEVELOPED BY SHAHARYAR SHAUKAT");
//
finput=new JFrame();
finput.setSize(400, 250);
finput.setVisible(false);
finput.setDefaultCloseOperation(JFrame.DISPOSE_ON_CLOSE);
finput.setResizable(false);
finput.setLocationRelativeTo(null);
finput.setLayout(null);
finput.setTitle("ENTER JOB");
load1();
load2();
txt1=new JTextField();
txt2=new JTextField();
txt3=new JTextField();
txt1.setBounds(10, 70, 50, 30);
finput.add(txt1);
txt1.setEditable(false);
txt2.setBounds(130, 70, 80, 30);
// Formatting TextField to invalid
txt2.addKeyListener(new KeyAdapter() {
   public void keyTyped(KeyEvent e) {
     char c = e.getKeyChar();
     if (!((c >= '0') && (c <= '9') ||
        (c == KeyEvent.VK_BACK_SPACE) ||
        (c == KeyEvent.VK_DELETE))) {
       getToolkit().beep();
       JOptionPane.showMessageDialog(null,
           "Character Not Allowed",
           "Invalid Input",
           JOptionPane.ERROR_MESSAGE);
       e.consume();
     }
   }
 });
txt3.addKeyListener(new KeyAdapter() {
   public void keyTyped(KeyEvent e) {
     char c = e.getKeyChar();
     if (!((c >= '0') && (c <= '9') ||
        (c == KeyEvent.VK_BACK_SPACE) ||
        (c == KeyEvent.VK_DELETE))) {
       getToolkit().beep();
       JOptionPane.showMessageDialog(null,
           "Character Not Allowed",
           "Invalid Input",
           JOptionPane.ERROR_MESSAGE);
       e.consume();
     }
   }
 });
finput.add(txt2);
txt3.setBounds(280, 70, 80, 30);
finput.add(txt3);
insert=new JButton("INSERT");
insert.setBackground(new Color(241, 196, 15));
insert.setForeground(Color.WHITE);
insert.setFont(new Font("Garamond",  Font.BOLD , 15));
insert.setBounds(10, 150, 100, 30);
insert.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
   loadData();
//table = new JTable( dataValues, columnNames );
f2.add(scrollPane);
txt1.setText(Integer.toString(c+1));
txt2.setText("");
txt3.setText("");

}
});
done=new JButton("DONE");
done.setBackground(new Color(241, 196, 15));//rgb(243, 156, 18)
done.setForeground(Color.WHITE);
done.setFont(new Font("Garamond",  Font.BOLD , 15));
done.setBounds(280, 150, 100, 30);
done.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
finput.setVisible(false);
}
});
colorc=new JButton("CHOOSE COLOR");
colorc.setBackground(new Color(243, 156, 18));
colorc.setForeground(Color.BLACK);
colorc.setFont(new Font("Garamond",  Font.BOLD , 12));
colorc.setBounds(120, 150, 150, 30);
colorc.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
color=JColorChooser.showDialog(null, "Assign Color to job", color);
}
});
finput.add(done);
finput.add(insert);
finput.add(colorc);
f1.validate();
}
public void load1(){
try{
BufferedImage bf = ImageIO.read(new File("icon//bg1.jpg"));
f1.setContentPane(new Bg(bf));

}catch(Exception e){

}
group = new ButtonGroup();
r1= new JRadioButton("FCFS",true);
r2= new JRadioButton("SJF");
r3= new JRadioButton("ROUND ROBIN");
group.add(r1);
group.add(r2);
group.add(r3);
r1.setBounds(20, 200, 60, 30);
r1.setBackground(Color.WHITE);
r2.setBounds(100, 200, 60, 30);
r2.setBackground(Color.WHITE);
r3.setBounds(170, 200, 100, 30);
r3.setBackground(Color.WHITE);
jb1=new JButton("NEXT");
jb1.setBackground(new Color(44, 62, 80));
jb1.setBounds(70, 250, 150, 50);
jb1.setForeground(Color.WHITE);
jb1.setFont(new Font("Garamond",  Font.BOLD , 30));
jb1.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
f1.dispose();
f2.setVisible(true);
}
});
f1.add(r1);
f1.add(r2);
f1.add(r3);
f1.add(jb1);
f1.validate();



}
public void load2(){
JobQueue=new LinkedList<Process>();
ReadyQueue=new LinkedList<Process>();
try{
BufferedImage bf = ImageIO.read(new File("icon//bg2.jpg"));
f2.setContentPane(new Bg(bf));

}catch(Exception e){

}
try{
BufferedImage bf = ImageIO.read(new File("icon//inputbg1.jpg"));
finput.setContentPane(new Bg(bf));

}catch(Exception e){

}
dataValues=new String[25][4];
inData();// initialize  dataValues to =""
table = new JTable( dataValues, columnNames );
table.setFont(new Font("Garamond",  Font.BOLD , 20));
table.setEnabled(false);
table.setRowHeight(30);
scrollPane = new JScrollPane( table );
scrollPane.setBounds(20, 150, 550, 400);
add=new JButton("ADD");
add.setBackground(new Color(231, 76, 60));
add.setForeground(Color.WHITE);
add.setFont(new Font("Garamond",  Font.BOLD , 25));
add.setBounds(600, 150, 150, 50);
add.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
txt1.setText(Integer.toString(c+1));
txt2.setText("");
txt3.setText("");
finput.setVisible(true);
}
});

delete=new JButton("DELETE");
delete.setBackground(new Color(231, 76, 60));
delete.setForeground(Color.WHITE);
delete.setFont(new Font("Garamond",  Font.BOLD , 25));
delete.setBounds(600, 250, 150, 50);
delete.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
deleteData();
//table = new JTable( dataValues, columnNames );
f2.add(scrollPane);
}
});

start=new JButton("START");
start.setBackground(new Color(231, 76, 60));
start.setForeground(Color.WHITE);
start.setFont(new Font("Garamond",  Font.BOLD , 25));
start.setBounds(600, 350, 150, 50);
start.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
prqObj=new PaintReadyQueue(totalTime);
// prqObj.temp=jobpool.JobQueue;
gcObj=new GanttChart(totalTime);
pbObj=new  ProgessBar(c,JobQueue);
load3();
f3.setVisible(true);
f2.setVisible(false);
if(r1.isSelected()){
FCFS();
}else if(r2.isSelected()){
SJF();
}else{
RR();
}
}
});

back=new JButton("BACK");
back.setBackground(new Color(231, 76, 60));
back.setForeground(Color.WHITE);
back.setFont(new Font("Garamond",  Font.BOLD , 25));
back.setBounds(600, 450, 150, 50);

f2.add(scrollPane);
f2.add(add);
f2.add(delete);
f2.add(start);
f2.add(back);
f2.validate();
}
public void load3(){
try{
BufferedImage bf = ImageIO.read(new File("icon//bgmain.jpg"));
f3.setContentPane(new Bg(bf));

}catch(Exception e){

}
avgTime=new JLabel();
avgTime.setBounds(425, 380, 200, 100);
avgTime.setFont(new Font("SansSerif", Font.BOLD, 50));
start2=new JButton("BEGIN");
start2.setBounds(10, 10, 150, 50);
scrollPane2 = new JScrollPane( table );
scrollPane2.setBounds(20, 90, 335, 380);
animation.setBounds(455, 188, 120, 110);
prqObj.setBounds(373, 87, 300, 80);
gcObj.setBounds(20, 510, 955, 110);
pbObj.setBounds(700, 120, 165, 350);
start2.addActionListener(new ActionListener(){
public void actionPerformed(ActionEvent e){
FCFS();
}
});

f3.add(avgTime);
f3.add(gcObj);
f3.add(animation);
f3.add(scrollPane2);
f3.add(prqObj);
f3.add(pbObj);
f3.validate();
f3.revalidate();
}//--------------------------------------------------------------------------
public void loadData(){

String str1=txt1.getText();
String str2=txt2.getText();
String str3=txt3.getText();
if(str2.isEmpty()||str3.isEmpty()||color==Color.WHITE){
getToolkit().beep();
if(color==Color.WHITE){
JOptionPane.showMessageDialog(null,"** Choose Color Apart From White","ERROR",JOptionPane.ERROR_MESSAGE);
}else{
JOptionPane.showMessageDialog(null,"** ALL Fields Are Required","ERROR",JOptionPane.ERROR_MESSAGE);
}
}else{
// load the the process in JobPool
dataValues[c][0]=Integer.toString(c+1);
dataValues[c][1]="JOB_"+str1;
dataValues[c][2]=str2;
dataValues[c][3]=str3;
totalTime=totalTime+ Integer.parseInt(str2);
//jobpool.InsertJob(c, Integer.parseInt(str3), Integer.parseInt(str2), color);
InsertJob(c, Integer.parseInt(str3), Integer.parseInt(str2), color);
c++;
color=Color.WHITE;
}
}
public void deleteData(){
//
if(c==0){
JOptionPane.showMessageDialog(null, "Job Pool is Empty, No Item For Deletion ");
}
else
{
c--;
dataValues[c][0]="";
dataValues[c][1]="";
dataValues[c][2]="";
dataValues[c][3]="";
}
}
//-----------------------------------------------
public void inData(){
for(int i=0;i<25;i++){
dataValues[i][0]="";
dataValues[i][1]="";
dataValues[i][2]="";
dataValues[i][3]="";

}
}
//----------------INSERT JOB TO JOBPOOL------------------
public void InsertJob(int id,int atime,int cputime,Color c){
JobQueue.add(new Process(id,atime,cputime,c));
}
//--------------------------UPDATE READY QUEUE--------------------------
public void updateReadyQueue(int t){
Process temp;
for(int i=0;i<JobQueue.size();i++){
temp=JobQueue.remove();
if(temp.getArrivalTime()==t){
insertProcess(temp);// Insert The Process To Ready Queue
JobQueue.add(temp);
}else{
JobQueue.add(temp);
}

}
}
//--------------------------INSERT PROCESS TO READY QUEUE-------------------
public void insertProcess(Process p){
ReadyQueue.add(p);


}
//--------------------------FCFS------------------------------
public void FCFS(){
int n=JobQueue.size();
Process CpuProcess;
CpuProcess=null;// Intilize null process
for(int i=0;i<totalTime;i++){
updateReadyQueue(i);
allQueue(i);
if(CpuProcess==null){
if(!ReadyQueue.isEmpty()){
CpuProcess=ReadyQueue.remove();
CpuProcess.setIstResponseTime(i);
CpuProcess.setLastResponseTime(i);
}
}
if(CpuProcess!=null){
CpuProcess.Decrement();
gcObj.temp.add(CpuProcess);
pbObj.JobQ.add(CpuProcess);
if(CpuProcess.getRemainingTime()==0){
CpuProcess.setWaitTime(i);
AvgWaitTime=AvgWaitTime+CpuProcess.getwaitingTime();
CpuProcess=null;
}

}

}
gcObj.JobQ.addAll(gcObj.temp);//  Gantt Chart Class
if(n>0){
//AvgWaitTime=AvgWaitTime/n;
displayResult=AvgWaitTime/n;
}
//avgTime.setText(Integer.toString(AvgWaitTime));
avgTime.setText(Float.toString(displayResult));
f3.add(avgTime);
f3.revalidate();
}
//------------------SJF----------------------------------------------
public void SJF(){
int n=JobQueue.size();
Process CpuProcess=null;
int state=0;
for(int i=0;i<totalTime;i++){
updateReadyQueue(i);
allQueue(i);
if(CpuProcess==null){
// means CPU is empty
if(!ReadyQueue.isEmpty()){
CpuProcess=loadminCpuBust();
}
}else{
if(!ReadyQueue.isEmpty()){
CpuProcess=checkPreemtion(CpuProcess);
}
}
if(CpuProcess!=null){
gcObj.temp.add(CpuProcess);
pbObj.JobQ.add(CpuProcess);
CpuProcess.Decrement();
if(CpuProcess.getRemainingTime()==0){
CpuProcess.setWaitTime(i);
AvgWaitTime=AvgWaitTime+CpuProcess.getwaitingTime();
CpuProcess=null;
}
}

}
gcObj.JobQ.addAll(gcObj.temp);
if(n>0){
//AvgWaitTime=AvgWaitTime/n;
displayResult=AvgWaitTime/n;
}
//avgTime.setText(Integer.toString(AvgWaitTime));
avgTime.setText(Float.toString(displayResult));
f3.add(avgTime);
f3.revalidate();
}
//------------------- LOAD MIN CPU BOUND PROCESS TO CPU-----------------------------------
public Process loadminCpuBust(){
int min,pos=0;
Process p,returnprocess;
Queue<Process> temp=new LinkedList<Process>();
temp.addAll(ReadyQueue);
returnprocess=temp.peek();
        min=temp.peek().getRemainingTime();
for(int i=0;i<temp.size();i++){
p=temp.poll();
if(p.getRemainingTime()<min){
min=p.getRemainingTime();
pos=i;
}
temp.add(p);
}
for(int i=0;i<temp.size();i++){
p=ReadyQueue.poll();
if(i==pos){
returnprocess=p;
}else{
ReadyQueue.add(p);
}

}
return returnprocess;

}
//---------------------------LOAD AND CHECK FOR PREEMPTION-----------------------
public Process checkPreemtion(Process p){
int min,pos=-1;
Queue<Process> temp=new LinkedList<Process>();
temp.addAll(ReadyQueue);
Process currentprocess=p,returnprocess=p,tp;
min=currentprocess.getRemainingTime();
for(int i=0;i<temp.size();i++){
tp=temp.poll();
if(tp.getRemainingTime()<min){
min=tp.getRemainingTime();
pos=i;
}
temp.add(tp);
}
if(pos>=0){
for(int i=0;i<temp.size();i++){
tp=ReadyQueue.poll();
if(i==pos){
returnprocess=tp;
ReadyQueue.add(currentprocess);
}else{
ReadyQueue.add(tp);
}

}
}

return returnprocess;
}
//--------------------------------------SJF ENDS -------------------------------------

//---------------------------------ROUND ROBIN--------------------------------------
public void RR(){
int n=JobQueue.size();
Process CpuProcess=null;
int quatum=0;
for(int i=0;i<totalTime;i++){
updateReadyQueue(i);
allQueue(i);
if(quatum==2||CpuProcess==null){
if(!ReadyQueue.isEmpty()){
CpuProcess=loadJob(CpuProcess,quatum);
CpuProcess.setLastResponseTime(i);
}
quatum=0;
}
if(CpuProcess!=null){
gcObj.temp.add(CpuProcess);
pbObj.JobQ.add(CpuProcess);
CpuProcess.Decrement();
quatum++;
if(CpuProcess.getRemainingTime()==0){
if(CpuProcess.getLastCpuBurst()!=0){
CpuProcess.setLastCpuBurst(quatum);
}
CpuProcess.setWaitTime(i);
AvgWaitTime=AvgWaitTime+CpuProcess.getwaitingTime();
CpuProcess=null;
}
}

}
gcObj.JobQ.addAll(gcObj.temp);
if(n>0){
displayResult=AvgWaitTime/n;
}
avgTime.setText(Float.toString(displayResult));
f3.add(avgTime);
f3.revalidate();
}

public Process loadJob(Process p ,int t){
if(p==null){
return ReadyQueue.remove();
}else{
ReadyQueue.add(p);
p.setLastCpuBurst(t);
return ReadyQueue.poll();
}
}

//--------------All Queue For PAINTREADYQUEUE CLASS----------------------
public void allQueue(int  t){
if(!ReadyQueue.isEmpty()){
prqObj.all.addAll(ReadyQueue);
prqObj.array[t]=ReadyQueue.size();
}else{
prqObj.array[t]=0;
}


}
public static void main(String args[]){
new App();
}

}

// BACKGROUND IMAGE CLASS

import java.awt.Graphics;

import java.awt.Image;

import javax.swing.JComponent;

public class Bg extends JComponent {

Image i;

public Bg(Image i) {

this.i = i;



}

public void paintComponent(Graphics g) {



g.drawImage(i, 0, 0, null);  // Drawing image using drawImage method



}

}

// CPU PROCESS CLASS

import java.awt.event.ActionEvent;

import java.awt.event.ActionListener;

import javax.swing.*;

import java.awt.*;

import java.util.LinkedList;

import java.util.Queue;

public class CpuProcess extends JPanel implements ActionListener{

private Timer tm;

int time;

int n;

int x;

int c=0;

public Process p=null;

public Queue<Process> JobQ,temp;

public CpuProcess(int t){

JobQ=new LinkedList<Process>();

temp=new LinkedList<Process>();

tm=new Timer(1000,this);

n=0;

x=5;

time=t;

tm.start();

}

public void actionPerformed(ActionEvent e) {

p=JobQ.remove();

   repaint();

   n++;

   if(n>=time){

    tm.stop();

   }

}

public void paint(Graphics g){

if(p!=null){

g.setColor(p.getColor());

g.fillRect(10, 10, 100,70);

g.setColor(Color.WHITE);

g.drawString(Integer.toString(1+p.getId()), 30, 25);

}

}

}

// GANTT CHART CLASS

import java.awt.event.ActionEvent;

import java.awt.event.ActionListener;

import javax.swing.*;

import java.awt.*;

import java.util.LinkedList;

import java.util.Queue;

public class GanttChart extends JPanel implements ActionListener {

private Timer tm;

int time;

int n;

int x;

int c=0;

public Process p;

public Queue<Process> JobQ,temp;

public GanttChart(int t){

JobQ=new LinkedList<Process>();

temp=new LinkedList<Process>();

tm=new Timer(1000,this);

n=0;

x=5;

time=t;

tm.start();

}

public void actionPerformed(ActionEvent e) {

temp.clear();

temp.addAll(JobQ);

n++;

x=10;

   repaint();

}

public void paint(Graphics g){

super.paint(g);

this.setBackground(Color.WHITE);

if(n>=time){

tm.stop();

}

for(int i=0;i<n;i++){

if(temp.size()>0){

g.setColor(temp.peek().getColor());

g.fillRect(x, 10, 15,80);

g.setColor(Color.WHITE);

g.drawString(Integer.toString(1+temp.peek().getId()), x, 25);

g.drawString(Integer.toString(1+i), x, 25+60);

x+=20;

temp.poll();

}

}

//g.fillRect(20, 300, 20, 40);

}

}

// JOB POOL CLASS

import java.awt.Color;

import java.util.LinkedList;

import java.util.Queue;

public class JobPool {

public Queue<Process> JobQueue,T,ReadQUeue,tempReadQUeue; // Job Queue to hold all job

PaintReadyQueue object;

public JobPool(){

JobQueue=new LinkedList<Process>();

T=new LinkedList<Process>();

ReadQUeue=new LinkedList<Process>();

tempReadQUeue=new LinkedList<Process>();

}

public void InsertJob(int id,int atime,int cputime,Color c){

JobQueue.add(new Process(id,atime,cputime,c));

T.add(new Process(id,atime,cputime,c));

}

public void insertReady(Process p){

ReadQUeue.add(p);

tempReadQUeue.add(p);

}

}
